Specifications
Compressor side:
- Ported shroud compressor housing
- Compressor wheel: in-house made, reinforced 54/67mm 9+0 blades machined from the solid aluminium
- Air Intake diameter:
- straight compressor housing – 63mm (2,5″)
- compressor housing with 90° elbow – 76mm (3″)
- Air outlet diameter: 51mm (2″)
Core:
- Bearings: dual ceramic ball bearings
- Cooling: water cooled bearing housing with 2 M14x1.5 ports
- Lubrication: AN4 oil inlet with integrated oil restrictor
Turbine side:
- Housing: single scroll 8cm2 / AR: 0.61
- Turbine wheel: custom design 56/53mm 9 blades
- Flange: T3 single scroll
- Exhaust connection: 3″ V-band clamp
